Oventrop Kolektore per Dysheme Inox Set Me 12 Dalje
336.00 EUR
Multidis SF heating circuit manifold for surface heating and cooling systems, with valve inserts M 30 x 1.5 that can be thermostatically controlled and integrated flow measuring and regulating devices 0-5 l/min., pre-assembled for 12 circuits. Flow distributor made of stainless steel (1.4301) with integrated flow measuring and regulating devices, with screw-in connection pieces, nickel-plated, with G ¾ externally threaded connection according to DIN EN 16313 (Eurocon) for Oventrop compression fittings with union nut, nickel-plated, with G 1 internal thread for the direct connection of a flat sealing ball valve, with connection for hose fitting DN 15, with vent plugs G ½, nickel-plated, with rotatable outlet, with blind plugs G ¾, nickel-plated. Return collector made of stainless steel (1.4301) with valve inserts M 30 x 1.5, with nipples, nickel-plated, with G ¾ externally threaded connection according to DIN EN 16313 (Eurocone) for Oventrop compression fittings with union nut, nickel-plated, with G 1 internally threaded connection for the direct connection of a flat sealing ball valve, with fill and drain cock, with connection for DN 15 hose, with vent plugs G ½, nickel-plated, with rotating outlet, with blind plugs G ¾, nickel-plated. Bracket (loosely added) made of galvanised steel for fixing the manifold inside the cabinet or onto the wall. Pipe clamps sound absorbing as per DIN 4109, sound insulation in building construction.
In stock
